FEATURES:
Floating die pressing system and Ejection
Constant(E.P.C)principle where the level of ejection of the part from the press
is always the same regardless of the part height.
Use of the die control system for positive
die movement and the secure flat-face die atopper design ensuring accurate
control of part dimensions,uniform density balance and consistant production.
The upper ram pressing motion is a toggle-link drive system for superior powder compression characteristics.
For tool changing and setting the dieset system is adopted for quick dieset changeover times and minimum press down-time capability,The press can be supplied for dieset changing at the front or the rear of the press.
The press design and construction is simple and straightforward resulting in reliable operation and reduced mechanical trouble while still maintaining the sophisticated controlled press motions for the production of intricate and complex parts.
The press drive and main moving structures are located at the base of the press giving the press a low center of gravity and inherently stable operation.
